Project Description
Ram Type Hydraulic Steering Gear
Ram Type Hydraulic Steering Gear is special used in the Chemical Tanker/ Oil Tanker and Liquid Gas vessel bigger than 10000DWT
Feature :New structure steering gear, use the open hydraulic circuit with solenoid valve control. Through the reciprocating movement of one ram to rotate the rudder blade through tiller to attain the purpose of control the ship’s course This steering gear is consists of twin ram type ram unit, two motor pump units and control valve units. It can be used in the Chemical Tanker/ Oil Tanker and Liquid Gas vessel bigger than 10000DWT which rudder turning time less than 28S/ 20S.
Certificate : CCS, BV, ABS, GL, NK,mill certificate etc
Country of Origin : CHINA
Main performance parameters ：
| Torque | Rudder turning angle | Rudder turning time | Working pressure | Design pressure | Power of motor | Outside measurement(mm) | ||
| Degree | s | A | B | C | ||||
| 2×320 | ±35° | ≤28S | 14.9 | 18.6 | 18.5 | 3610 | 2000 | 900 |
| 2×350 | ±35° | ≤28S | 14.9 | 18.6 | 18.5 | 3914 | 2300 | 900 |
| 2×400 | ±35° | ≤28S | 13.5 | 16.9 | 18.5 | 3914 | 2300 | 965 |
| 2×450 | ±35° | ≤28S | 15 | 18.8 | 22 | 3914 | 2300 | 965 |
| 2×500 | ±35° | ≤28S | 16.5 | 20.6 | 22 | 3914 | 2300 | 965 |
* Please contact us for final confirmation on above data before you place order.
