Project Description
JIS F 2005-1975 Closed Chock
Closed chocks are used for temporary mooring to guide rope from inboard to outboard a large vessel. Used at the vessel’s bow bulwarks to prevent wear and tear of mooring line. Welded at bow ships.
Certificate : CCS , BV, ABS , mill certificate etc
Treatment: Painted Primer or Galvanized or according to Customer’s request
Country of Origin : CHINA
250-500
Nominal | L | L1 | B | H | H1 | Weight | Dia of Rope | |
Dia. | (mm) | (mm) | (mm) | (mm) | (mm) | KG | Wire | Hemp |
250 | 250 | 434 | 160 | 200 | 372 | 48 | 20 | 50 |
300 | 300 | 528 | 200 | 250 | 464 | 82 | 22 | 60 |
350 | 350 | 600 | 220 | 250 | 485 | 103 | 24 | 70 |
400 | 400 | 672 | 240 | 250 | 506 | 136 | 26 | 80 |
450 | 450 | 746 | 260 | 250 | 528 | 184 | 30 | 85 |
500 | 500 | 820 | 280 | 250 | 550 | 232 | 36 | 90 |
* Please contact us for final confirmation on above data before you place order.
