Project Description
Electric Rotary Vane Steering Gear
Advantage Compact in structure, small in dimension, light in weight, low noise and big rudder angle (up to 2×65 º ). Own on the rudder, can use up sleeve keyless connection with the rudder stock.
Certificate : CCS, BV, ABS, GL, NK,mill certificate etc
Country of Origin : CHINA
Main performance parameters ：
| Torque | Rudder stock dia. | Rudder turning angle | Weight /KG | ||
| 63kN.m | ≤Φ170mm | ±35° | ±45° | 500 | |
| 75kN.m | ≤Φ180mm | ±35° | ±45° | ±65° | 1380 |
| 120kN.m | ≤Φ240mm | ±35° | ±45° | ±65° | 1650 |
| 160kN.m | ≤Φ280mm | ±35° | ±45° | 1750 | |
| 250kN.m | ≤Φ300mm | ±35° | ±45° | ±65° | 3000 |
| 320kN.m | ≤Φ320mm | ±35° | ±45° | 3200 | |
| 400kN.m | ≤Φ350mm | ±35° | ±45° | 3600 | |
| 500kN.m | ≤Φ370mm | ±45° | ±65° | 4000 | |
| 630kN.m | ≤Φ390mm | ±35° | ±45° | 5000 | |
| 800kN.m | ≤Φ420mm | ±35° | ±45° | 5000 | |
| 1000kN.m | ≤Φ450mm | ±45° | ±65° | 5000 | |
* Please contact us for final confirmation on above data before you place order.
