CYZ Series Self-Priming Centrifugal Oil Transfer Pump

Certificate: ABS, BV, CCS, GL, RINA etc.

CYZ Series Self-Priming Centrifugal Oil Transfer Pump Advantage:

1.Good Quality
2. Large displacement and high effciency
3. Easy to operate
4. Fast Delivery

Widely used in ship terminal station oil tanker wharf, tankers airport, Respectively transport gasoline kerosene diesel fuel, etc. Transmission of medium temperature from – 20c to 80c, Viscosity below 100 pearl and the solid content of less than 30%

This is a kind of self-priming centrifugal pump, featured by a compacted structure, easy to operate, easy to maintain, high efficiency, long-life, strong self-priming capacity, etc. When it is used in oil tanker or other ships, it can double as stripping pump, ship ballast pump, Marine fire pump.The pump was made of high quality materials, sealing the calculation with hard alloy mechanical seal, durable, spit out line does not need to install the safety valve, inlet line does not need to install the bottom valve, thus simplifies the pipeline system, and improve the working conditions.

MODEL	CAPACITY	HEAD	self-priming	RPM	NPSH
			time
	( m3/h)	(m)	(min)	r/min	m
25CYZ-20	3.2	20	2	2900	3
25CYZ32	3.2	32	2		3
32CYZ50	3.2	50	2		3
40CYZ-20	6.3	20	2		3
40CYZ-32	6.3	32	2		3
40CYZ-40	10	40	2		3.5
40CYZ-50	6.3	50	2		3.5
50CYZ-12	12.5	12	2		3.5
50CYZ-20	15	20	2		3.5
50CYZ-30	12.5	30	2		3.5
50CYZ-35	12.5	35	2		3.5
50CYZ-40	12.5	40	2		3.5
50CYZ-50	12.5	50	2		3.5
50CYZ-60	12.5	60	2		3.5
50CYZ-75	15	75	2		3.5
65CYZ-15	30	15	2.5		3.5
65CYZ-32	25	32	2		3.5
65CYZ-50	25	50	2		3.5
65CYZ-70	25	70	2		3.5
80CYZ-13	35	13	3.4		4.5
80CYZ-17	43	17	3		4.5
80CYZ-22	40	22	2.5		4.5
80CYZ-25	50	25	2.5		4.5
80CYZ-32	50	32	2		4
80CYZ-40	50	40	2		4
80CYZ-55	60	55	2		4
80CYZ-70	60	70	2		4
100CYZ-20	80	20	2		4.5
100CYZ-25	100	25	2		4.5
100CYZ-32	100	32	2		4.5
100CYZ-40	100	40	2		4
100CYZ-50	100	50	2		4
100CYZ-65	100	65	2		4
100CYZ-75	80	75	2		4
150CYZ-15	180	20	2.5	1450	3
150CYZ-30	180	30	2.5	1450	3.5
150CYZ-45	160	45	2	2900	4.5
150CYZ-55	160	55	2		4.5
150CYZ-65	160	65	2		4.5
150CYZ-80	160	80	2		4.5
200CYZ-32	400	32	2	1450	4
200CYZ-63	280	63	2		4
250CYZ-50	400	50	2		4
300CYZ-50	500	50	2		4
